Dr. Beal’s Seed Viability Experiment

In 1879, Dr. William J. Beal buried 20 jars full of sand and seeds on the grounds of Michigan State University. He was hoping to answer questions about seed dormancy and long-term seed viability. Farmers and gardeners have often wondered: “How many years would one have to spend weeding until there are no more weeds left to pull?” Seeds only remain viable for so long, so if weeds were removed before having a chance to make more seeds, the seed bank could, theoretically, be depleted over time. This ignores, of course, the consistent and persistent introduction of weed seeds from elsewhere, but that’s beside the point. The question is still worth asking, and the study still worth doing.

When Dr. Beal set up the experiment, he expected it would last about 100 years, as one jar would be tested every 5 years. However, things changed, and Dr. Beal’s study is now in its 140th year, making it the longest-running scientific experiment to date. If things go as planned, the study will continue until at least 2100. That’s because 40 years into the study, a jar had to be extracted in the spring instead of the fall, as had been done previously, and at that point it was decided to test the remaining jars at 10 year intervals. In 1990, things changed again when the period was extended to 20 years between jars. The 15th jar was tested in 2000, which means the next test will occur in the spring of next year.

In preparing the study, Dr. Beal filled each of the 20 narrow-necked pint jars with a mixture of moist sand and 50 seeds each of 21 plant species. All but one of the species (Thuja occidentalis) were common weeds. He buried the jars upside down – “so that water would not accumulate about the seeds” – about 20 inches below ground. Near each bottle he also buried seeds of red oak and black walnut, but they all rotted away early in the study.

After the retrieval of each bottle, the sand and seed mixture is dumped into trays and exposed to conditions suitable for germination. The number of germinates are then counted and recorded. Over the years, the majority of the seeds have lost their viability. In 2000, only three species germinated  – Verbascum blattaria, a Verbascum hybrid, and Malva rotundifolia. There were only two individuals of the Verbascum hybrid, and only one Malva rotundifolia. The seeds of Verbascum blattaria, however, produced 23 individuals, suggesting that even after 120 years, the seeds of this species could potentially remain viable long into the future.

moth mullein (Verbascum blattaria)

In the 2000 test, the single seedling of Malva rotundifolia germinated after a cold treatment. Had the cold treatment not been tried, germination may not have occurred, which begs the question, how many seeds in previous studies would have germinated if subjected to additional treatments? Dr. Beal himself had wondered this, expressing that the results he had seen were “indefinite and far from satisfactory.” He admitted that he had “never felt certain that [he] had induced all sound seeds to germinate.”

There are also some questions about the seeds themselves. For example, the authors of the 2000 report speculate that poor germination seen in Malva rotundifolia over most of the study period could be “the result of poor seed set rather than loss of long-term viability.” The presence of a Verbascum hybrid also calls into question the original source of those particular seeds. A report published in 1922 questions whether or not the seeds of Thuja occidentalis were ever actually added to the jars, and also expresses uncertainty about the identify of a couple other species in the study.

Despite these minor issues, Dr. Beal’s study has shed a great deal of light on questions of seed dormancy and long-term seed viability and has inspired numerous related studies. While questions about weeds were the inspiration for the study, the things we have been able to learn about seed banks has implications beyond agriculture. Seed bank dynamics are particularly important in conservation and restoration. If plants that have disappeared due to human activity have maintained a seed bank in the soil, there is potential for the original population to be restored.

In future posts we will dive deeper into seed banks, seed dormancy, and germination. In the meantime, you can read more about Dr. Beal’s seed viability study by visiting the following links:

Advertisements

Seed Oddities: Vivipary

Seeds house and protect infant plants. When released from their parent plant, they commence a journey that, if successful, will bring them to a suitable location where they can take up residence (upon germination) and carry out a life similar to that of their parents. Their seed coats (and often – in the case of angiosperms – the fruits they were born in) help direct them and protect them in this journey. Physical and chemical factors inhibit them from germinating prematurely – a phenomenon known as dormancy. Agents of dispersal and mechanisms of dormancy allow seeds to travel through time and space — promises of new plants yet to be realized.

There is rarely a need for a seed to germinate immediately upon reaching maturity. In many cases, such as in temperate climates or in times of drought or low light, germinating too soon could be detrimental. The most vulnerable time in a plant’s life comes when it is a young seedling. Thus, finding the right time and space to get a good start is imperative.

The fruits (and accompanying seeds) of doubleclaw (Proboscidea parviflora) are well equipped for long distance dispersal. (via wikimedia commons)

In rare instances, dispersal via seeds offers little advantage; instead, dispersal of live seedlings or propagules is preferable. For this select group of plants, vivipary is part of the reproductive strategy. In vivipary, seeds lack dormancy. Rather than waiting to be dispersed before germinating, viviparous seeds germinate inside of fruits that are still attached to their parent plants.

Occasionally, seeds are observed germinating inside tomatoes, citrus, squash, and other fruits; however, these fruits are usually overripe and often detached from the plant. In these instances, what is referred to as “vivipary” is not a genetic predisposition or part of the reproductive strategy. It’s just happenstance – a fun anomaly. The type of vivipary discussed in this post is actually quite rare, occurring in only a handful of species and prevalent in a select number of environments.

There are three main types of vivipary: true vivipary, cryptovivipary, and pseudovivipary. In true vivipary, a seed germinates inside the fruit and pushes through the fruit wall before the fruit is released. In cryptovivipary, a seed germinates inside the fruit but remains inside until after the fruit drops or splits open. Pseudovivipary is the production of bulbils or plantlets in the flower head. It does not involve seeds and is, instead, a form of asexual reproduction that will be discussed in a future post.

True vivipary is commonly seen among plant communities located in shallow, marine habitats in tropical or subtropical regions, such as mangroves or seagrasses. The term mangrove is used generally to describe a community of plants found in coastal areas growing in saline or brackish water. It also refers more specifically to the small trees and shrubs found in such environments. While not all mangrove species are viviparous, many of them are.

Seedlings of viviparous mangrove species emerge from the fruit and drop from the plant into the salty water below. From there they have the potential to float long or short distances before taking root. They may land in the soil upright, but often, as the tide recedes, they find themselves lying horizontally on the soil. Luckily, they have the remarkable ability to take root and quickly stand themselves up. Doing this allows young plants to keep their “heads” above water as the tides return. It also helps protect the shoot tips from herbivory.

Viviparous seedlings emerging from the fruits of red mangrove (Rhizophora mangle) via wikimedia commons

Another example of vivipary is found in the epiphytic cactus (and close relative of tan hua), Epiphyllum phyllanthus. Commonly known as climbing cactus, this species was studied by researchers in Brazil who harvested fruits at various stages to observe the development of the viviparous seedlings. They then planted the seedlings on three different substrates to evaluate their survival and establishment.

Epiphyllum phyllanthus is cryptoviviparous, so the germinated seeds don’t leave the fruit until after it splits open. In a sense, the mother plant is caring for her offspring before sending them out into the world. The researchers see this as “a form of parental care with subsequent conspecific [belonging to the same species] nursing.” Since the plant is epiphytic – meaning that it grows on the surface of another plant rather than in the soil – local dispersal is important, since there is no guarantee that seeds or propagules dispersed away from the host plant will find another suitable site. That being said, the researchers believe that “vivipary involves adaptation to local dispersal,” since “the greater the dispersal distance is, the higher the risk and the lower the probability of optimal dispersion.”

Epiphyllum phyllanthus via Useful Tropical Plants

While some viviparous seedlings of mangroves can travel long distances from their parent plant and don’t always root into the ground immediately, they maintain their advantage over seeds because they can root in quickly upon reaching a suitable site and lift themselves up above rising tide waters. As the authors of the Epiphyllum study put it, vivipary is “a reproductive advantage that, in addition to allowing propagules to root and grow almost immediately, favors quick establishment whenever seedlings land on suitable substrates.”

There is still much to learn about this unusual and rare botanical feature. The research that does exist is relatively scant, so it will be interesting to see what more we can discover. For now, check out the following resources:

Also, check out this You Tube video of :

Seed Dispersal via Caching – The Story of Antelope Bitterbrush

Generally speaking, individual plants produce an enormous amount of seeds. This may seem like a huge waste of resources, but the reality is that while each seed has the potential to grow into an adult plant that will one day produce seeds of its own, relatively few may achieve this. Some seeds will be eaten before they get a chance to germinate. Others germinate and soon die from lack of water, disease, or herbivory. Those that make it past the seedling stage continue to face similar pressures. Reaching adulthood, then, is a remarkable achievement.

Antelope bitterbrush is a shrub that produces hundreds of seeds per individual. Each seed is about the size of an apple seed. Some seeds may be eaten right away. Others fall to the ground and are ignored. But a large number are collected by rodents and either stored in burrows (larder hoarding) or in shallow depressions in the soil (scatter hoarding). It is through caching that antelope bitterbrush seeds are best dispersed. When rodents fail to return to caches during the winter, the seeds are free to sprout in the spring. Some of the seedlings will dry out and others will be eaten, but a few will survive, making the effort to produce all those seeds worth it in the end.

Fruits forming on antelope bitterbrush (Purshia tridentata)

Antelope bitterbrush (Purshia tridentata) is in the rose family and is often simply referred to as bitterbrush. It occurs in grasslands, shrub steppes, and dry woodlands throughout large sections of western North America. It is a deciduous shrub that generally reaches between three and nine feet tall but can grow up to twelve feet. It has wedge-shaped leaves that are green on top, grayish on bottom, and three-lobed. Flowers are yellow, strongly fragrant, and similar in appearance to others in the rose family. Flowering occurs mid-spring to early summer. Fruits are achenes – single seeds surrounded by papery or leathery coverings. The covering must rot away or be removed by animals before the seed can germinate.

Bitterbrush is an important species for wildlife. It is browsed by mule deer, pronghorn antelope, bighorn sheep, and other ungulates, including livestock. It provides cover for birds, rodents, reptiles, and ungulates. Its seeds are collected by harvester ants and rodents, its foliage is consumed by tent caterpillars and other insects, and its flowers are visited by a suite of pollinators. For all that it offers to the animal kingdom, it also relies on it for pollination and seed dispersal. The flowers of bitterbrush are self-incompatible, and if it wasn’t for ants and rodents, the heavy seeds – left to rely on wind and gravity – would have trouble getting any further than just a few feet from the parent plant.

Antelope bitterbrush (Purshia tridentata) in full bloom – photo credit: wikimedia commons

In a study published in The American Naturalist (February 1993), Stephen Vander Wall reported that yellow pine chipmunks were the primary dispersal agents of bitterbrush seeds in his Sierra Nevada study area. The optimal depth for seedling establishment was between 10-30 millimeters. Seeds that are cached too near the surface risk being pushed out of the ground during freeze and thaw cycles where they can desiccate upon germination. Cached bitterbrush seeds benefit when there are several seeds per cache because, as Vander Wall notes, “clumps of seedlings are better able to push through the soil and can establish from greater depths than single seedlings.”

Another study by Vander Wall, published in Ecology (October 1994), reiterated the importance of seed caching by yellow pine chipmunks in the establishment of bitterbrush seedlings. Seed caches, which consisted of anywhere from two to over a hundred seeds, were located as far as 25 meters from the parent plant. Cached seeds are occasionally moved to another location, but Vander Wall found that even these secondary caches produce seedlings. Of course, not all of the seedlings that sprout grow to maturity. Vander Wall states, “attrition over the years gradually reduces the number of seedlings within clumps.” Yet, more than half of the mature shrubs he observed in his study consisted of two or more individuals, leading him to conclude that “they arose from rodent caches.”

A study published in the Journal of Range Management (January 1996) looked at the herbivory of bitterbrush seedlings by rodents. In the introduction the authors discuss how “rodents [may] not only benefit from antelope bitterbrush seed caches as a future seed source, but also benefit from the sprouting of their caches as they return to graze the cotyledons of germinating seeds.”  In this study, Ord’s kangaroo rats, deer mice, and Great Basin pocket mice were all observed consuming bitterbrush seedlings, preferring them even when millet was offered as an alternative. The two species of mice also dug up seedlings, possibly searching for ungerminated seeds. Despite seed dispersal via caching, an overabundance of rodents can result in few bitterbrush seedlings reaching maturity.

A cluster of antelope bitterbrush seedlings that has been browsed. “Succulent, young seedlings are thought to be important in the diets of rodents during early spring because of the nutrients and water they contain.” — Vander Wall (1994)

———————

Photos of antelope bitterbrush seedling clusters were taken at Idaho Botanical Garden, where numerous clusters are presently on display along the pathways of the native plant gardens and the adjoining natural areas.
